low temperature charging batteries 18650 3.6V DC2800mah 3.7V lithium ion battery HL18650V
2900mah 3.6V 3.7V 2800mAh 10A High low temperature battery for e-call vehicle emergency call system
HL18650V 2900mAh 10A (H&L temp.)
-40 ~ +85℃ HL18650V 2900mah 3.7V 2900mAh 10A lithium battery 18650
3.6V High temperature HL18650V Li-ion battery, it can work on -40°C~+85°C, 2900mAh.
Wide Temperature Lithium Batteries · HL18650T-2900mAh
This is a special lithium battery 18650 cell that can working at high and low temperature
Charge operation temprature:
-20~60°C,
-20<T≤-10°C.0.05Cto 4.1V
-10<T≤0°C;0.1C to 4.1V
0<T≤10°C;0.2C to 4.2V
10<T<60°C;0.5C to 4.2V
Discharge operation temprature:
-40~85°C
0<T≤85°C;2.75V
-20<T≤0℃C;2.5V
-40≤T≤-20°C;2.0V
18650V rechargeable battery spec.
| Part number | HL18650V |
| Capacity | Typical 2900mah, Minimum 2800mah |
| Nominal Voltage | 3.7 volt |
| Dimensions | D18.3+-0.2 * H64.95+-0.2 mm |
| Wokring voltage | 2.75V-4.2V |
| Maximum continuous charge/discharge | 1.4A / 10A |
| Cycle life (25 ℃,0.5 C / 1C ) | up to 500Cycle |
| -40 ℃ Capacity (0.2 C) | ≈70% |
| 80 ℃ 1000 hours aging | >85% |
| Charge temperature | -20~60℃ |
| Discharge temperature | -40~85℃ |
| OEM and ODM | Welcome |
Other hot sale 18650 lithium ion battery list:
| Model | Capacity | Min. capacity | Continuous discharge | Internal resistance | Certificate |
| 18650F56 | 2200 | 2180mAh | 1C | ≤ 60mΩ | ULCBBISUNBSMI |
| 18650F8R | 2600 | 2550mAh | 1C(2550mA) | ≤ 60mΩ | ULCBBISUNBSMI |
| 18650F9L | 3350 | 3250mAh | 0.5C (1625mA)(-20~5℃) 1.5C (4875mA)(5~50℃) |
≤ 60mΩ | ULCBBISUNBSMI |
| 18650F30 | 3000 | 2900mAh | 1C | ≤ 60mΩ | ULCBBISUNBSMI |
| 18650F30P | 3000 | 2900mAh | 20A 30A( 80℃) |
≤ 18mΩ | ULCBBISUNBSMI |
| 21700F2E | 5000 | 4900mAh | 3.0C(14400mA) (70℃) |
≤ 25mΩ | ULCBBISUNBSMI |
| 18650F8L | 2600 | 2500mAh | 3C | ≤ 25mΩ(≥ 4.15V) | ULCBBISUNBSMI |
| 18650F8M7 | 2600 | 2500mAh | 3C | ≤ 30mΩ | ULCBBISUNBSMI |
| 18650F8P | 2500 | 2500mAh | 20A 30A(80℃) |
≤ 18mΩ | ULCBBISUNBSMI |
| 18650F9E | 3500 | 3450mAh | 10000mA | ≤ 40mΩ | ULCBBISUNBSMI |
| 18650F9M | 3200 | 3100mAh | 3.0C(9300mA) | ≤ 40mΩ | ULCBBISUNBSMI |
