Place of Origin:
China
Brand Name:
OEM
Certification:
Meet UL
Model Number:
nimh button cell
40H NI-MH button NiMH rechargeable battery 40mAh 1.2V nimh 40H 60H 80H 160H 110H
40mAh Rechargeable 1.2V NiMH 40H Flat Top Button Batteries Battery Solar
40H1.2V Ni-MH BUTTON CELL
| Part number | 40H |
| Voltage | 1.2V |
| Capacity | 40mah |
|
Recommended Trickle Charge Current |
0.4~1.2mA |
|
Nominal Charge Current |
4mA |
|
Normal Charging Time |
14~16h |
|
Nominal Discharge Current |
8mA |
| Weight | 1.8g |
| Cycle Life | ≥500 |
| Discharge cut-off voltage | 1.0 v |
RATINGS
Nominal voltage : 1.2V
Nominal capacity : 40mAh/0.2CmA
Typical weight : 1.8g
Standard charge : 4mA×14hours
Rapid charge : 8mA×6.5hours
Trickle current : 0.4mA
Discharge cut-off voltage: 1.0V
Temperature range for operation (Humidity: Max.85%)
Standard charge 0~+35℃
Rapid charge 0~+35℃
Trickle charge 0~+35℃
Discharge 0~+35℃
Temperature range for storage (Humidity: Max.85%)
Within 1 years 0~+25℃
Within 6 months -20~+35℃
Within a month -20~+45℃
Within a week -20~+55℃
40H rechargeable battery NI-Mh 40mah battery
Coin cell NIMH battery 1.2v rechargeable button cell:
| Cell model | Voltage(V) | Capacity(mah) | Diameter(mm) | Height(mm) | Charge current(mA) | Discharge current(mA) | Weight(g) | Temperature(°C) |
| 20H | 1.2 | 20 | 11.7±0.1 | 3.2±0.2 | 2 | 4 | 1.5 | 0~45 |
| 40H | 1.2 | 40 | 11.7±0.1 | 5.2±0.2 | 4 | 8 | 1.8 | 0~45 |
| 60H | 1.2 | 60 | 15.3±0.1 | 6.1±0.2 | 6 | 12 | 2 | 0~45 |
| 80H | 1.2 | 80 | 15.3±0.1 | 6.1±0.2 | 8 | 16 | 3.5 | 0~45 |
| 110H | 1.2 | 110 | 15.3±0.1 | 7.7±0.2 | 10 | 20 | 4.5 | 0~45 |
| 160H | 1.2 | 150 | 24.5*14±0.1 | 5.2±0.2 | 15 | 30 | 6 | 0~45 |
| 250H | 1.2 | 250 | 25±0.1 | 6.3±0.2 | 25 | 50 | 10 | 0~45 |
| 330H | 1.2 | 330 | 25±0.1 | 8.4±0.2 | 30 | 60 | 12.5 | 0~45 |
